BIOLOGICAL SAFETY CABINET CLASS II B2
MSC-B1100
Medallion Equipment’s UK
Introduction:
The AC Series Class II B2 Biological Safety Cabinet is a high-performance containment unit
designed for laboratories handling hazardous biological materials and chemical compounds.
Unlike traditional Class II cabinets, the B2 model provides 100% total exhaust, ensuring that all
potentially harmful air is completely expelled from the laboratory, making it ideal for
applications requiring both biological and chemical safety.
Features:
1. Color key display: large screen, more clear and dynamic display of various values of the safety
cabinet, and has the function of appointment timing.
2. Automatically adjust the wind speed.
3. With power-off memory function, the state before power-off will be restored after power-on,
and there will be visual prompts and alarms.
4. The integrated design of the operation area makes it easy to disassemble and clean.
5. The cabinet is separated from the base. The height of the adjustable base can be customized.
6. Interlocking function: UV lamp and front window; UV lamp and fan, LED lamp; fan and front
window.
7. It has the function of appointment timing, which can automatically set the time of starting and
shutting down the safety cabinet and the running time of ultraviolet lamps, fans and sockets.
8. The front window closes the double trigger signal,so that the sterilization and disinfection
function of the ultraviolet lamp is normally turned on.
9. The negative pressure air duct is equipped with a foreign matter filtering structure to prevent
foreign matter such as paper scraps from entering the fan system and affecting the normal
operation of the product.
10. The front window glass has a one-key lift function.
11. The cabinet is designed with a 10° inclination angle, which is in line with ergonomic
principles, with a larger viewing angle, convenient operation and more humanization.
12. The one-piece hand rest has a large fat surface, which has a larger contact area with the arm
and is more comfortable.
Technical Parameters:
| Model |
MSC-B1100 |
| Max Opening |
480mm |
| Inflow Velocity |
0.53±0.025m/s |
| Downflow Velocity |
0.33±0.025m/s |
| ULPA Filter |
Two, 99.9995% efficiency at0.12pm, filter life indicator |
| Front Window |
Motorized. Two-layer laminated toughened glass>6mm. Anti UV |
| Noise |
<65dB |
| UV Lamp |
30W*1
UV timer, UV life indicator, emission of 235.7 nanometers for most efficient decontamination |
| LED Lamp |
12W*2 |
| Illumination |
>1000Lux |
| Consumption |
1300W |
| Waterproof Socket |
Two, total load of two sockets: 500W |
| Display |
LCD display: exhaust filter and down flow filter pressure, filter and UV lamp working time, inflow and down flow velocity, filter life, humidity and temperature, system working time etc |
| Control System |
Microprocessor |
| Airflow System |
0% air recirculation, 100% air exhaust |
| Visual and Audio Alarm |
Abnormal airflow velocity, Filter replacement, Front window at unsafe height, High filter pressure alarm, abnormal power failure |
| Material |
Work Zone: 304 stainless steel
Main Body: Cold-rolled steel with anti-bacteria powder coating |
| Work Surface Height |
770mm(can be customized) |
| Caster |
Foot master caster |
| Power Supply |
AC220V, 50/60Hz; 110V, 60Hz |
| Standard Accessory |
LED lamp 2pcs, UV lamp 2pcs, Base stand. Remote control, Foot switch, Drain valve, Waterproof socket 2pcs, Exhaust blower, Exhaust duct |
| External Size(W*D*H) |
1100*775*2250mm |
| Internal Size(W*D*H) |
940*600*660mm |
| Tested Opening |
Safety height 200mm(8″) |
| Package |
Main Body Exhaust
Blower(W*D*H) |
1230*990*1840mm |
| 930*800*700mm |
|
|
|
|
