Technical Parameters:
| Model No. | MFH-P1200 |
| External Size (W*D*H) | 1247*800*2450mm |
| Internal Size (W*D*H) | 987*560*700mm |
| Work Surface Height | 820mm |
| Max Opening | 740mm |
| Air Velocity | 0.3~0.8m/s |
| Noise | ≤68dB |
| Exhaust Duct | 4.3 meters, φ250mm |
| LED Lamp | 12W*2 |
| Blower | Built-in PP centrifugal blower |
| Front Window | Resistant to acid and alkali, Manual, 5mm toughened glass, height adjustable |
| Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz |
| Consumption | 400W |
| Material Main Body | Made of Porcelain white PP, thickness 8mm, resistant to strong acid, alkali and anti-corrosion. |
| Work Table | Chemical resistant phenolic resin |
| Standard Accessory | LED light; |
| Worktable: Chemical resistant phenolic resin; | |
| 4.3 meters PVC duct | |
| Pipe strap*2 | |
| RVV power cord(3*1.0mm²*3000mm); | |
| Base cabinet. | |
| Waterproof socket*2. | |
| Tail insert. | |
| Water tap (PP); | |
| Gas tap (PP). | |
| Water Sink. | |
| PP centrifugal blower*1 | |
| Optional Accessory | PP worktable, epoxy resin board or ceramic board. |
| Active carbon filter. | |
| Outer PP centrifugal blower*1 | |
| Splitable base cabinet | |
| Gross Main Body | 155kg |
| Weight Base Cabine | 99kg or 90kg (Splitable) |
| Package Size Main Body | 1388*938*1612mm |
| (W*D*H) Base Cabine | 1388*888*1000mm or 1400*1000*450mm(Splicable) |
