Introduction：
This machine uses a streamlined design, with advanced features, stable and reliable performance and ease of use.
Features:
* Large-volume removable waste tray on the top of housing, convenient to use.
* Imported cross-roller guide rails andhigh-precision screw motion mechanism.
* Fast switching between paraffin block clamp and cassette clamp.
* Hand-wheel balance can be precisely adjustedand can be locked at any position,ensuring safetyand convenience of
sectioning.
* Blade holder can be laterally movedwithout direct contact,enabling use of the entire length of the blade. (three different
segments)
* The red bar on the blade holder covers the whole length of blade to protect the user and enables easy change of the blade.
* Automatic sectioning speed is adjustable. (MK-98)
* Auto slicing controller ensures trimming and slicing switching easily; When it is off, semi-auto slicing or trimming is
available.(MK-98)
* Safety and emergency braking systems (MK-98)，security alarm systems, driver-overload protection and auto-sleep
protection system.(For all 3 models)
* Control system with 3 modes: conventional mode, intelligence sensing mode and whole layer cutting mode.(MK-98)
Technical Parameters:
| Model | MK-98 |
| Mode | Automatic or Manual |
| Display | Sectioning thickness, Trimming thickness, Slice count, Slice speed |
| Trimming Thickness Range | 1 ~ 600 µm |
| Increment | |
| 1 ~ 10 µm | 1 µm |
| 10 ~ 20 µm | 2 µm |
| 20 ~ 50 µm | 5 µm |
| 50 ~ 150 µm | 10 µm |
| 150 ~ 600 µm | 50 µm |
| Whole Layer Clearance Distance (Only for BK-2488) | Not applicable |
| Specimen Horizontal Stroke | 28 mm |
| Specimen Orientation | XY-8° rotation (±90°) |
| External Size (WDH) | 580 x 475 x 340 mm |
| Consumption | 150W |
| Package Size (WDH) | 680 x 570 x 500 mm |
| Gross Weight | 60 kg |
