Features:
- Build-in open type water tank
The sterilizer adopts easy-clean open type water tank which can support repeated program running if fully injected with water.
- High-efficiency ultimate vacuum
The sterilizer adopts high-efficiency low noise vacuum system which has excellent effects.
- Large LCD display
The LCD screen can display temperature, pressure, time, operating status, failure warning and other information. It is convenient for customers to observe the sterilizer running status.
- Multiple program types
The system has various programs that include solid instruments, packaged instruments, fabric(dressing) program, and enhance program. The other three are test programs, namely HELIX test, B&D test, and vacuum test.
- Standard USB port
Users can store the sterilization data with USB disk.
- Optional mini printer can be attached to record the process of sterilization.
- High-efficiency air filter: 0.22μm sterilizing high-efficiency air filter, the filtration efficiency is not less than 99.5%, to ensure that the vacuum-breaking air is sterile air, and to avoid re-contamination of sterile materials.
- Safety protection
Automatic power-off protection for over-temperature and over-pressure, anti-dry burning protection device, automatic pressure relief device for over-pressure, over-current protection device, and leakage protection device.
- Built-in waste water tank
Technical Parameters:
| Model | MTA-Z24 |
| Capacity | 23L |
| Door | Manual |
| Display | 3.5-inch LCD |
| Designed Pressure | -0.1/0.28MPa |
| Working Pressure | 0.23Mpa |
| Max Designed Temp. | 150℃ |
| Working Temp. | 121/134℃ |
| Temp. Precision | 0.1℃ |
| Sterilization Time | 0~60min |
| Drying Time | 0~20min |
| Water Tank Capacity | 3.5L |
| Vacuum System | High efficiency vacuum pump |
| Chamber Material | S30408 |
| Chamber Size | φ247*470mm |
| Altitude | ≤2700m |
| Rack | 1 rack with 4 trays |
| Standard Accessories | Aluminum tray, USB port |
| Optional Accessories | Stainless steel tray, printer |
| Consumption | 1.95KW |
| Power Supply | AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional) |
| External Size(W*D*H) | 495*700*410mm |
| Net Weight | 55kg |
| Package Size(W*D*H) | 610*810*590mm |
| Gross Weight | 67kg |
