Features:
* High quality servo motor.
*Multi-steps rotate speed, temperature and time control systems.* Slow accelerate and decelerate design.
*Advantaged air duct design.
*Automatic defrosting function.*High-precision speed control.
*High-precision temperature control.*Unique drive system.
*Open door protection.
*LCD display with bright illumination.
*Memorized and protected operating parameters.*Continuously running or timing.
*Unique slow-start design.
*Standard of illumination and UV light.
Technical Parameters:
| Model | MSI-N2012 |
| Controller | PID |
| Display | LCD |
| Circulation Mode | Forced convection |
| Shaking Mode | Rotary shaking |
| Drive Mode | Multidimensional drive |
| Rotating Speed | 20-350rpm (Top layer 20-300rpm, static culture, reverse rotation or alternate operation) |
| Rotating Accuracy | ±1rpm |
| Vibration Range | Φ26mm (Can customize φ35 (20-250rpm/min); φ50(20-200rpm/min)) |
| Temp. Range | 4~65℃(At25℃) |
| Temp.Control Accuracy | ±0.1℃ |
| Temp. Uniformity | ±0.6℃ (At 37℃) |
| Timing Range | 0~9999h/min |
| Shaking Plate Size | 610*460 mm |
| Shaking Plate Quantity | 1 pc |
| Max. Capacity | 250ml*32or500ml*21 or1000ml*13or2000ml*7(Flask clamp)
250ml*32or500ml*20or1000ml*12or2000ml*8(haftplatte) |
| Standard Capacity | 500ml*21 |
| Internal Material | Stainless steel |
| External Material | Stainless steel |
| Heating Consumption | 800-900W |
| Safety Function | Audio and visual alarm for over-temperature; Alarm for over-speeds;
Independent over-temperature protector; Shutdown protection for door opening; Leakage or over-current protection; Ultraviolet disinfection function; Calibration of monitoring temperature and ambient temperature; Overload protection of refrigeration unit and delayed start of incoming call (only BJPX-2012RN) |
| Consumption | 1200W |
| Power Supply | Standard:220V±10%, 50Hz; optional:110V±10%, 50Hz |
| Internal Size(W*D*H)(mm) | 715*580*450(per unit) |
| External Size(W*D*H)(mm) | 1120*790*620(per unit) |
| Package Size(W*D*H)(mm) | 1275*950*810(per unit) |
| Gross Weight | 240(per unit) |
