Technical Parameters:
| Model No. | MXT-100 |
| Viewing Head | Sliding Trinocular Head Inclined at 45? |
| Nosepiece | Ball Beating Quadruple Nosepiece |
| Eyepiece | WF10X/18mm |
| Objective | Achromatic 4X,10X,40X(S)100X(S,O) |
| Stage | Double Layer Mechanical Stage 135*140mm |
| Condenser | ABBE NA1.25 condenser with Iris Diaphragm & filter, rack & pinion adjustable |
| Illumination | Build-in Illumination, Halogen lamp6V/20W, Power supply 90-230V |
| Camera | 5 megapixel |
| Power Supply | AC110/220V±10%,50/60Hz |
| Optional Accessory | Camera, Monitor |
| Package | Cartoon with foam |
| Package Size | 250*360*460mm |
| Gross Weight | 8kg |
| Image Sensor | 1/3 SONY CCD | Video Output | BNC 1.0VP-P.75 |
| Signal System | PAL/NTSC | Backlight Compensation | OFF/ON |
| Scanning Frequency | Horizontal:15.62KHz Vertical:50Hz | Electronic Shuttle | AUTO IRIS EE |
| Horizontal Resolution | 480TV/520TV | Camera Interface | CS |
| Min Illumination | F1.2 0.5LUX
0.01 LUX |
Balance | Auto |
| Gain Control | Auto | Power | DC 12V |
| 48S/N Ratio | 50dB AGC |
