Technical Parameters:
| Model No. | MBM-1000 | |
| Viewing Head | Siedentop hinged binocular viewing head, inclined at 30°, 360° rotatable,Interpupillary48~75mm |
|
| Eyepiece | WF10×/18 | |
| P16×/11 (Op | ||
| Objective | Achromatic objective 4×,10×,40×,100× | |
| Plan achromatic objective 4×,10×,40×,100× (Optional) | ||
| Infinite plan achromatic objective 4×,10×,40×, 100× (Optional) | ||
| Nosepiece | Quadruple nosepiece | |
| Focusing | Coaxial coarse & fine adjustment, fine division 0.002mm, coarse stroke 37.7mm per rotation,fine stroke 0.2mm per rotation ,moving range 20mm. |
|
| Stage | Double layers mechanical stage: 32*142mm, moving range:75*40mm | |
| Condenser | Abbe condenser NA1.25 with aperture diaphragm | |
| Illumination | S-LED Illumination,brightness adjustable 12V/ 20W Halogen lamp, brightness adjustable (Optional) Kohler illumination (Optional) |
|
| Power Supply | 110~220V, 50/60Hz | |
| Accessories | Photo attachment, video attachment Dark field condensor (Optinal) | |
| Package Size | 323*264*440 | |
| Gross Weight | 6.5kg |
