Technical Parameters:
| Model No. | MSC-A42 | |
| External size(W*D*H) | 1383*775*2295mm | |
| Internal Size(W*D*H) | 1210*600*660mm | |
| Work Surface Height Max Opening Tested Opening |
750mm with optional base stand | |
| 550mm (22’’) | ||
| Safety height 200mm (8”) | ||
| Airflow Volume | Inflow | 462m3/h(272cfm) |
| Down flow | 65%:863m3/h(507cfm) | |
| Exhaust | 35%:462m3/h(272cfm) | |
| Front Window | Motorized. Two-layer laminated toughened glass ≥5mm. | |
| Anti UV | ||
| HEPA Filter | Two, 99.995% efficiency at 0.3μm, filter life indicator | |
| Filter Guard Type | Aluminum alloy frame , glass filter paper | |
| Noise | NSF 49≤67 dB/EN 12469≤65 dB | |
| Illumination | ≥1000Lux | |
| Display | LCD Display | |
| Waterproof Socket Tap | 2, Total consumption:≤500W Water tap*1, Gas tap *1 | |
| Ground Resistance | ≤ 0.10Ω | |
| Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz, Full load Amps: | |
| 9A, BTU/Hr: 1689 | ||
| Consumption | 500W | |
| Alarm DC Motor | Abnormal airflow velocity; Filter replacement; Front window at | |
| unsafe height. | ||
| One ECM motor, 110V& 220V acceptable, Speed adjust-able, high | ||
| efficiency low power consumption | ||
| Material | Working area: 304stainless steel | |
| Frame and Decorative Plate: cold-rolled steel with | ||
| anti-bacteria power coating | ||
| UV Lamp | 30W | |
| Germicidal UV lamp, Emission of 253.7 nanometers for most | ||
| most efficient decontamination | ||
| Illuminating Lamp | 18W*2 | |
| LED lamp | ||
| Standard Accessory | Illuminating lamp, UV lamp *2, Base stand, SS water & | |
| gas taps, Drain valve, Waterproof sockets, Stainless Steel | ||
| I.V. Bar with 10 hooks | ||
| Optional Accessory | Armrest, Airflow tester, Formalin fumigation sterilizer, Infrared | |
| Infrared sterilizer, Electric height adjustable base stand, | ||
| Remote control | ||
| Package Size(W*D*H) | 1540*1080*1900mm | |
| Gross Weight | 340kg | |
