Features
- With easily operated touching switch, solve the problem of limited service life of mechanical keypad and keypad invalid due to constantly operating
- Insert touching switch in the 2 pcs side rail at the head side, for patient adjust bed posture easily. Also a touching switch system at the foot board, with Patient Lock-Out system, for nursing person’s operation
- Back-rest, Leg-rest, High-low, Trendelenburg, Trendelenburg all by electrically controlled with indicator light to show the work status
- Black & Leg linkage movement: back-rest and leg-rest can up at the same time, supply convenient operation
- With the “reset” button to make the bed be flat and lowest from any position
- Back battery, for emergency power failure
- Detachable head & foot board in PP plastic, can be fixed when assembled
- 4 pcs drop-down PP protective railing, controlled by gas spring
- Bed board with soft connection, make the bending of the bed board more smooth to let the patient feel more comfortable when lying in the bed
- Central brake castors, brake the un-brake controlled by electric-operation
- V pole mount bracket, at 4 corners of the bed frame
- X-ray translucent backrest
- X-ray cassette tray, Urine bag rail with hooks
- 4-section mattress platform with extension of ≥10 cm
- Easy-chair & Cardiac-chair position by one button
- Motorized + manual CPR function
- Auto-regression system
- Directional lock on the castors
Specification
| PARAMETER | SPECIFICATION |
| Material | Steel frame work, Top class ABS&PP plastic |
| Dimension | 2240mm(L)*1050(W)*500mm(W)-750mm |
| Bed Board | 1940mm(L)*900mm(W) |
| Hi-Low | 750mm-500mm（±5mm） (from bed board to ground) |
| Back-Rest | 0-63° |
| Leg-Rest | 0-40° |
| Trendelenburg | 0~12º |
| Anti-trendelenburg | 0~12º |
| Net Weight | 148kg |
| Load Capacity | ~250kg |
| Castor | Φ150mm Universal (Central Brake). Electric brake & un-brake |
